Central unit RD2502

"Slim line" type, for audio broadcast of 2 stereo sound sources, expandable up to 260 zones, with stabilized power supply 24V 6,5A included.
The system can have automatic switch-on and function control for every audio source.


Main features:

• 2 stereo inputs AUX type (CD, HD, TUNER, MP3, MINI, PC, SAT, etc) adjustable sensitivity 0,5
• 2 V through trimmers on the rear panel, stereo RCA sockets
• 1 active input with priority, sensitivity 12 Vpp (for MC1501 microphone modules, MCZ501 paging stations, etc)
• Stabilized built-in power supply, low noise, short-circuit protection, 24Vdc 6,5A (able to supply 20 active speakers type 508/530-10, 50 type 503, 10 type 530-20, or 7 type 530-30)
• 2 plugs for SUF and STIF cards for functions control of sound sources
• 2 stereo outputs 12Vpp standard
• Output for automatic switch-on of external power supplies
• Switched mains socket 110/230 Vac, 200W max

Using the optional accessories, it is suitable for installation on standard 19’’ rack mounts. The overall size is 1 rack unit.

Power supply: 110/230 Vac, 50/60 Hz

Dimensions: H 44 x W 430 x D 325 mm
Weight: 4 kg
