PSRS4353V compact amplifier, 350W, 6 zones complete with audio sources for 100V constant voltage loudspeaker lines.
Built-in audio sources: Bluetooth receiver, DAB/FM radio, MP3 player (USB).
Line and microphone inputs also with phantom power.
Possibility of connection with dedicated MCC506 active paging station for selective calls.
Compact dimensions, 2U for 19" rack.

Other features:

  • High-visibility OLED display for easy operation.
  • Audio source selector: FM, DAB+, Bluetooth, MP3 player (USB).
  • Digital volume controls for high precision.
  • Master volume control.
  • 3 priority levels: EMC > Mic1 > other sources.
  • Very wide frequency response with low noise and distortion.
  • 6.3 mm jack microphone input on front panel with independent volume.
  • 2 balanced microphone inputs with independent volume control and selectable phantom power.
  • 1 switchable Mic/Aux input.
  • Aux output for connection to other devices.
  • 2 Aux inputs with independent volume control.
  • Mute function with automatic adjustment.
  • EMC input, with volume control, for connection to alarm signalling devices.
  • 6 adjustable 100V outputs with selective microphone call on each zone.

230 VAC  selectable and 24 V dc protection fuse on support frame.
Colour: black
Dimensions: 88 x 470 x 338 mm.
Weight: 16,4 kg
